7-Pole Chebyshev Low-Pass Filter – 12 MHz Cutoff Frequency

Applications:

• Multi-Pole Filter

Features:

• Multi-Pole Filter Footprint on Both Sides of PCB
• Ground Plane and 50 Ω Transmission Line
• SMA Male/Female Connectors
• Metal Enclosure Included for Shielding
• 0.44″ W x 0.37″ H outside dimension, 2.06″ L

Description:

The PRL-LPF7 is a 7-pole Chebyshev Low-Pass Filter, built from our popular PRL-MNET-SMF Signal Conditioning Kit, populated with standard value surface-mount components.

The 12 MHz variant was designed and built as an application-specific model for a customer. It is now available as a stock item, but no performance metrics are published. Performance as described below is representative, but not guaranteed.
