Description

This is a solid, reliable 16-Volt Charger for any Antigravity Lithium 16V Battery such as our VTX20 motorsports battery and our new H6-30-16 race car/truck battery. Works with other brands of 16-Volt Lifepo4 vehicle batteries as well.

Note: Never use a 16v Charger on a 12v Battery, nor a 12v Charger on a 16v Battery. Use this charger ONLY with 16v Lifepo4 Lithium Motorsports Batteries.

• 16-Volt Lithium Motorsports Battery Charger
• Fast 5-Amp charge rate
• Multiple protections
• Comes with attached Clamps

AG-BC-16V Lithium Battery Charger

The Antigravity 16-Volt Charger works with 110 or 220 voltage. Foreign countries just need an adapter for the plug.

This 16-Volt Charger works with any 16V Antigravity Battery, and should ONLY be used with 16V Batteries. With a 5-amp charge rate it offers a fast charge and is a solid, reliable unit for maintaining 16-Volt Lifepo4 batteries.

Features

• Advanced high frequency switching mode power supply technology.
• DC output isolated from AC input.
• Single Input ll0Vac and 230Vac or Universal Input 110/230Vac, 50Hz-60Hz.
• Charging parameters are insensitive to the AC input line voltage variations.
• Completely automatic battery charging: CC, CV.
• Two LEDs: LED1 indicates Power On or Off. LED2 indicates Charging/Charged.
• LED SCREEN indicates charging Voltage and Current.
• Short-circuit, over-voltage, over-temperature, reverse-polarity protections.
• Efficiency > 85%.
• Forced ventilation with fans.
• 100% full load burn-in test.

Operation

1. Connect the Charger to the Wall Outlet/Power Supply.
2. Connect the Charger to the Battery making sure Polarity is correctly connected to the Battery.
   Red Clamps to Positive (+) Battery Connection
   Black Clamps to Negative (-) Battery Connection
3. LED1: indicates the Charger is plugged in. RED LED confirms the AC power is on.
4. LED2: Green confirms the Charger is connected. FLASHES Red/Green when charging.
5. LED2: will show GREEN SOLID LED when the battery is fully charged.
