FuelTech Staging and Brake Control Solid-State Relay

Description

FEATURES

This relay can be used for the following:

• FT600 / FT550 / FT500 / FT500LITE / FT450 built-in Staging Control
• FT600 / FT550 / FT500 / FT500LITE / FT450 built-in Brake Control

Fast switching speed which is perfect for PWM control and for use as a normal relay. No mechanical parts inside. Silent operation.

• 12V Solid State Relay
• Max Current: 20A
• PWM frequency: 0-1000Hz

Dimensions (L x W x H): 27mm x 27mm x 26mm (1.07in x 1.07in x 1.02in)
Weight: 30g

ELECTRICAL CONNECTIONS:

• 30 – Switched 12V – Use fuse
• 85 – Not connected
• 86 – Trigger – FT auxiliary output (activated when switched to ground)
• 87 – Output for load – Normally Open contact – 20A:

 Staging / Brake Control Relay Diagram
