Remote-Mount Hydraulic Clutch Master Cylinder Assembly – Adjustable Pushrod

Description

Remote Mount Clutch master cylinder assembly

• Wilwood Billet 4oz Reservoir with bracket
• Wilwood Non-Integral Girling Style Clutch Master Cylinder
• 6AN Pushlock Straight Hose end
• 6AN – 6AN ORB 90 Fitting
• 6AN Male Banjo with 7/16-20 Bolt Aluminum Fitting

To Determine bore size on a Backdraft roadster look into the driver side of the engine bay, and check the bellhousing for a clutch fork and slave installation. If the vehicle is equipped with an internal hydraulic throwout bearing instead of a traditional slave and fork, we recommend a 0.70″ bore clutch master. OE bore is 0.75″ and it’s recommended for vehicles with a traditional slave cylinder and fork.
