Rotel A10MKII – Compact Integrated Amplifier with Modern Connectivity

Description

• Description
• Features
• Specifications

• The A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience. Constructed with a massive Rotel-built toroidal transformer, the A10MKII delivers 50 Watts per channel of Class A/B power into 8 ohms featuring three RCA inputs and a Moving Magnet Phono stage for vinyl lovers.

  Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A10MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher into more challenging loudspeakers.

  All analog sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.

  An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analog volume controller extend ease of use to the listening seat.

  The A10MKII is available in both black and silver colors.

• FEATURES:

  2 x 50 Watts of robust power, 8 Ohms

  Includes remote control

  Moving Magnet Phono input for turntable connection

  Class AB amplifier design

  High current power supply

• SPECIFICATIONS:

  DIMENSIONS (W × H × D)430 × 73 × 347mm
  17” x 2 7/8” x 13 5/8” FRONT PANEL HEIGHT60 mm (2 3/8”) POWER REQUIREMENTS120V, 60Hz POWER CONSUMPTION150W STANDBY POWER CONSUMPTION<0.5W NET WEIGHT6.6 kg, 14.5 lbs BTU RATING (4Ω, 1/8th power)450 BTU/h
  POWER OUTPUT50W/Ch (All channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD)<0.03% FREQUENCY RESPONSELine Level Inputs: 10Hz – 100kHz, -0.5dB, +0.05dBPhono Input: 20Hz – 20kHz, -0.5dB, +0.3dB S/N RATIO (IHF “A” Weighted)
  Line Level Inputs: 90dBPhono Input: 85dB
  INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)<0.03% DAMPING FACTOR120  INPUT SENSITIVITYLine Level Inputs: 120mVPhono Input (MM): 1.5mV INPUT IMPEDANCELine Level Inputs: 45kΩPhono Input (MM): 43kΩINPUT OVERLOADLine Level Inputs: 4VPhono Input: 50mV TONE CONTROLS±6dB at 100Hz / 10kHz
